| KM9-M3401-H0X PLATE H. FEEDER 1 |
| 2 KM9-M3402-H0X GUIDE H-1. TAPE 1 |
| 3 KM9-M3403-H0X GUIDE H-2. TAPE 1 |
| 4 KM0-M3405-01X STAND. 1 1 |
| 5 KM0-M3406-01X STAND. 2 1 |
| 6 KM9-M3408-H0X BRACKET H.VALVE 1 |
| 7 KM9-M3409-H0X COVER H. VALVE 1 |
| 8 KGA-M3410-20X VALVE ASSY. 20 1 |
| 9 BF4BU-M3-70W JOINT 20 |
| 10 BF4BU JOINT 20 |
| 11 TT8-01 JOINT 1 |
| 12 TL8-01 JOINT 1 |
| 13 KM-06 MAFFLER 3 |
| 14 91317-06020 BOLT. HEX SOCKET 4 |
| 15 91317-04010 BOLT. HEX SOCKET 8 |
| 16 98903-04008 SCREW. BINDING HEAD 10 |
| 17 KG2-M3407-A0X AIR JOINT 20 |
| 18 KM0-M3416-00X GASKET 20 |
| 19 98907-03004 SCREW. BINDING HEAD 20 |
| 20 91317-08020 BOLT. HEX SOCKET HEAD 2 |
| 21 91317-03006 BOLT. HEX SOCKET HEAD 4 |
| 22 KM0-M3417-00X GUIDE 4 2 |
| 23 92990-04400 WASHER EXTL. TOOHED |
| KG2-M3401-B2X PLATE B. FEEDER 1 |
| 2 KM0-M3402-B0X GUIDE B-1. TAPE 1 |
| 3 KG2-M3403-B1X GUIDE B-2. TAPE 1 |
| 4 KM0-M3405-01X STAND. 1 1 |
| 5 KM0-M3406-01X STAND. 2 1 |
| 6 KM0-M3408-B0X BRACKET B. VALVE 1 |
| 7 KL0-M3409-B1X COVER B. VALVE 1 |
| 8 KGA-M3410-30X VALVE ASSY, 16-R 1 |
| 9 BF4BU-M3-70W JOINT 16 |
| 10 BF4BU JOINT 16 |
| 11 TT8-01 JOINT 1 |
| 12 TL8-01 JOINT 1 |
| 13 KM-06 MAFFLER 3 |
| 14 91317-06020 BOLT. HEX SOCKET 4 |
| 15 91317-04010 BOLT. HEX SOCKET 12 |
| 16 98903-04008 SCREW. BINDING HEAD 8 |
| 17 KG2-M3407-A0X AIR JOINT 16 |
| 18 KM0-M3416-00X GASKET 16 |
| 19 98907-03004 SCREW. BINDING HEAD 16 |
| 20 91317-08020 BOLT. HEX SOCKET HEAD 2 |
| 21 91317-03006 BOLT. HEX SOCKET HEAD 4 |
| 22 KM0-M3417-00X GUIDE4 2 |
| 23 92990-04400 WASHER EXTL. TOOHED |
| KV1-M2211-00X FRAME X AXIS 1 |
| 2 KV1-M2213-01X PLATE A, X AXIS 1 |
| 3 KV1-M2214-01X PLATE B, X AXIS 1 |
| 4 KV7-M2663-00X NYLOCK BOLT 16 M5X16 |
| 5 KM0-M2220-00X COUPLING, X-AXIS 2 |
| 6 KV7-M2231-00X SPACER R, NUT 2 |
| 7 KV1-M2233-00X SPACER R2 NUT 2 |
| 8 KV1-M2236-00X PLATE A 1 |
| 9 KV1-M2236-10X PLATE A-2 1 |
| 10 KV1-M2237-00X PLATE B 2 |
| 11 KV1-M2239-00X BRACKET 1 4 |
| 12 KV1-M2240-00X BRACKET 2 2 |
| 13 KM0-M2241-00X HOLDER, MOTOR X AXIS 2 |
| 14 KV7-M2242-00X HOLDER, BRG. X AXIS 2 |
| 15 KV7-M2645-00X BRG., ANGULAR 2 |
| 16 KV1-M2261-00X HOLDER, HEAD 2 |
| 17 KV7-M2271-01X SCREW BALL X AXIS 2 |
| 18 KV7-M2604-00X SUPPORT UNIT 2 |
| 19 90K56-8717EX AC SERVO MOTOR 2 |
| 2003.04 M340073 |
| 20 KV7-M653A-00X SENSOR, 1 2 L=600 |
| 21 KV7-M653E-00X SENSOR, 2 2 L=600 |
| 22 K47-M2276-S0X X-AXIS GUIDE SET 2 |
| 23 KV7-M2267-01X CABLE, DUCT 2 |
| 2004.07 MA70035 |
| 24 KV7-M221A-A0X COVER, DUCT ASSY 2 |
| 25 KV7-M2282-00X DOG, ORG 1 |
| 26 KV1-M2282-00X DOG, ORG 1 |
| 27 KV7-M2283-00X DOG, 2ND LIMIT 4 |
| 28 KV1-M226B-00X PLATE 2 |
| 29 KV7-M2291-00X BRACKET, SENSOR 1 |
| 30 KGA-M2651-10X DAMPER 14 ASSY 2 |
| 31 KGA-M2651-70X DAMPER 125 ASSY 2 |
| 32 KGA-M2649-00X NYLOCK BOLT 24 M2.6X10 |
| 33 KM0-M2251-00X NYLOCK BOLT 16 M8X22L |
| 34 KM0-M2252-00X STOPPER 1 |
| 35 KV1-M226A-00X COVER CABLE 1 |
| 36 KV7-M2268-00X BRACKET 1, TAPE 2 |
| 37 KV7-M2269-00X BRACKET 2, TAPE 2 |
| 38 KV7-M220A-01X TAPE , X DUCT 2 |
| 39 KV7-M220B-00X TAPE 2, X DUCT 2 |
| 40 KV7-M220C-00X TAPE 3, X DUCT 2 |
| 41 KV7-M2266-00X PLATE, NUT 4 |
| 42 KV7-M2240-00X SLEEVE, BRG. 2 |
| 43 KV7-M2243-00X HOUSING, BRG. X 2 |
| 44 KV7-M2244-00X COVER, BRG. HOUSING 2 |
| 45 KV7-M2246-00X COIL SPRING 12 |
| 46 KV7-M2647-00X OIL SEAL 4 |
| 47 KV7-M2648-00X SPACER 6 |
| 48 KG2-M9173-00X LOCK NUT 2 |
| 49 KV7-M2256-00X GRIP 2 |
| 50 KV7-M2257-00X SPACER, GRIP 2 |
| 51 91317-03006 BOLT HEX. SOCKET HEAD 24 |
| 52 91317-04006 BOLT HEX. SOCKET HEAD 8 |
| 53 91317-04008 BOLT HEX. SOCKET HEAD 16 |
| 54 91317-04010 BOLT HEX. SOCKET HEAD 50 |
| 55 KV7-M2251-00X NYLOCK BOLT 30 M4X16 |
| 56 91317-04030 BOLT HEX. SOCKET HEAD 12 |
| 57 91317-05014 BOLT HEX. SOCKET HEAD 4 |
| 58 91317-05020 BOLT HEX. SOCKET HEAD 4 |
| 59 91317-05035 BOLT HEX. SOCKET HEAD 4 |
| 60 91317-06012 BOLT HEX. SOCKET HEAD 8 |
| 61 91317-06018 BOLT HEX. SOCKET HEAD 26 |
| 62 98907-03005 SCREW BINDING HEAD 8 |
| 63 92017-06016 BOLT BUTTON HEAD 8 |
| 64 99480-06014 PIN, PARALLEL 4 |
| 65 KV1-M2291-00X BRACKET, SENSOR 1 |
| 66 KV1-M2295-00X BRACKET, PIN 2 |
| 67 KV1-M2296-00X BRACKET, SCREW 4 |
| 68 KV1-M2298-00X NYLOCK SET, SCREW 8 |
| 69 KV7-M2297-00X TAPER PIN 4 8X30 |
| 70 KV1-M2292-00X STOPPER |
