    Automated Optical Inspection PCB BF-Frontier II Saki AOI Machine

    Ask Lasest Price
    Brand Name : SAKI
    Model Number : SAKI BF-Frontier II
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal, Credit card
    Supply Ability : 10 Piece/Pieces per Week
    Delivery Time : 3 days
    • Product Details
    • Company Profile

    Automated Optical Inspection PCB BF-Frontier II Saki AOI Machine

    Automated Optical Inspection PCB BF-Frontier II Saki AOI Machine


    Hardware that provides both high-speed, and high reliability

    High-speed vibration-free line scan technology


    Optical system includes a telecentric lens capturing images with no blind spots


    Coaxial overhead lighting eliminates shadowing, improves capability and reduces production start-up time


    Advanced Software Features

    Line scan system detects FOD and extra components across the entire surface of the PCB


    Unique Fujiyama algorithm verifies five critical aspects of through-hole solder joints


    Conformal coating UV light inspection


    Improved floorspace productivity

    Benchtop Inspection System Product Line

    Compact machine design

    Machine width is the same for both single-lane and dual-lane


    Dimensions
    (W) x (D) x (H) [Main body]mm (in.)
    850 x 1340 x 1230
    (33.5 x 52.8 x 48.4)
    WeightApprox. 450 Kg (992.1 lbs)
    Electric Power RequirementSingle-phase ~ 100-120/200-240V +/-10%, 50/60Hz
    Resolution18μm
    Air Requirement0.5MPa, 5L/min (ANR)
    Target PCB Size
    mm (in.)
    50 W x 60 L - 460 W x 500 L
    (2 W x 2.4 L - 18 W x 20 L)
    PCB ClearanceTop: 40mm (1.57 in.)
    Bottom: 40mm (1.57 in.)

    Automated Optical Inspection PCB BF-Frontier II Saki AOI MachineAutomated Optical Inspection PCB BF-Frontier II Saki AOI MachineAutomated Optical Inspection PCB BF-Frontier II Saki AOI MachineAutomated Optical Inspection PCB BF-Frontier II Saki AOI Machine

    Automated Optical Inspection PCB BF-Frontier II Saki AOI Machine

    Automated Optical Inspection PCB BF-Frontier II Saki AOI Machine
