High precision Off-line Multi Blades Automatic PCB Depaneler Machine PCB Cutting Machine Separator Depanelizer

Y-S168CS1 Depanelizer series mainly uses the high-speed operation of milling cutter, dual platform four-axis servo drive to separate the multi connected PCB, according to the pre programmed path, replacing the manual breaking or V-CUT or push cutting defects, stress damage, improving product quality and reducing scrap rate. The machine adopts man-computer interface and AC servo motor.

WIN7 system operating interface. It uses high-pixel CCD production program to teach and edit the cutting path. It can be modified and simulated in a single step. It uses two servo moving platforms. As a PCB exchange device for upper and lower substrates, it can effectively reduce the idle time of the machine, thereby achieving higher production efficiency and quality. The software has MAKE compensation, same workbench duplication, double workbench duplication, equipped with large, medium and small three windows for more precise programming, adding a rectangular frame on the basis of the original target, programming is more intuitive and accurate programming, MAKE geometric alignment is automatically captured, The two tables are completely independent of parameters. Compared with the traditional three-axis machine, the response is faster, the parameters are more independent, the efficiency is higher, and the cutting accuracy is more guaranteed.

Visual system:
High-pixel color CCD and large magnification lens can assist program teaching and editing simulation functions. The automatic MARK positioning and correction system improves the cutting accuracy and prevents the board from being damaged due to the board not being in place. It is faster to copy left and right programs and switch models. Optional barcode reading function to realize 1D/2D barcode reading and save or upload, which is convenient for traceability and digital management.

High-speed spindle:
The imported high-speed spindle uses the German SycoTec(Kavo) spindle motor widely used in the industry's high-end splitters. The spindle has a high speed(60000rpm/min), long service life, convenient assembly and disassembly, and a smooth cutting surface without burrs and defects. It is also equipped with the original SycoTec 4424 Spindle frequency converter, which allows the spindle motor to have a longer service life, higher cutting torque, and the lowest temperature rise effect.

other machine

wenzhan Techonologies Co.,Ltd

In 2009, Shenzhen wenzhan Technology Co., Ltd. was established to build a more timely and effective communication platform, and realize the company's service tenet of serving leading customers.The engineers of the company are professional technicians who have been certified by the original factory for more than 10 years. They always adhere to the value of putting the interests of customers first, and provide customers with high-quality equipment accessories, consumables, fixtures and technical support services.

In order to effectively reduce the cost of customers, the company set up a machining plant, and changed most of the feeder parts to self-produced parts, so as to ensure sufficient inventory and reduce the cost of customers at the same time.

Why Choose Us?
It is precisely because wenzhan technology has the following advantages over the same industry that
more and more customers choose wenzhan as their preferred supplier.

1. Professional pre-sales advice support

2. Excellent after-sales technical service

3. Flexible payment and return policy

4. One stop solution for SMT accessories

5. Stock in the factory with sufficient stock and fast delivery

Shenzhen WenZhan electronic technology co., LTD. Is a professional SMT pick&place machine and the machine parts service providers.Company mainly provide SAMSUNG SMT machine parts/YAMAHA SMT machine parts/FUJI SMT machine parts/ ,

SMT machine parts/JUKI SMT machine parts/SONY SMT machine parts’ sales and maintenance services.

Our company supplies different kinds of products. High quality and favorable price.
We're pleased to get your Inquiry and we will come back to as soon as possible.
We stick to the principle of "quality first, service first, continuous improvement and
innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. T
o perfect our service, we provide the products with good quality at the reasonable price.

Photos on exhibition

SMT machines and related products:
1.SMT equipment and accessories,nozzles, feeder, feeder parts, cutter, filter, guide, tape, mortor, belt, cylinder,

smt grease/lubricant, THK grease gun ,bearing,SMD parts counter,sensor etc.
2. Nozzles & feeders&their parts for fuji, for Juki, for Yamaha, for Samsung, for Siemens, for ,

for Sony....etc,all of them have large stock.
3. We sell and recycle used SMT machine
