SMD Assembly Machine FUJI XPF-L PCB Pick And Place Machine

Ask Lasest Price
Brand Name :	FUJI
Model Number :	XPF-L
Supply Ability :	10 Piece/Pieces per Week
Price :	Negotiable
Payment Terms :	T/T, Western Union, Paypal, Credit card
Delivery Time :	3-5days

Add to Cart

Product Details
Company Profile

SMD Assembly Machine FUJI XPF-L PCB Pick And Place Machine

SMT Placement Machine Fuji XPF Pick And Place Machine PCB SMD assembly machine

Name: FUJI pick and place machine
Brand: FUJI
Model: FUJI XPF-L pick and place machine
Specification: FUJI XPF-L pick and place machine
Condition: original/copy
Quality: top qualiy
Stock: large
Payment: L/C T/T D/P Western Union Paypal Money Gram And Others
Shipment: In three days
Warranty: 1 year
Delivery: fedex,ups,dhl,as required
Package: carton box with foam protect

SPEC

FUJI XPF-L Specification:
The XPF is the world's first machine to feature dynamic head exchange.
The machine can switch between a high-speed placing head and a multi-purpose head automatically during production to

ensure that the most efficient head for the current task is being used.
This includes the ability to switch to a glue head, meaning that glue application and part placement can be performed at the

same machine.
Part Size:
01005 to 68x68mm Depending on Head Type
Speed:
* Revolver Head: 25,000 cph
* Single Nozzle: 9,000 cph
* M4 Auto Tool: Up to 10,500 cph
* Glue Tool: 0.2 sec/shot

PCB loading time: 1.8 sec
PCB size (LXW): Up to 457 x 356 mm
Thickness 0.4 (0.3) to 5.0 mm
Machine Dimensions:

L: 1,500 mm, W: 1,607.5 mm, H: 1,419.5 mm
Machine body XPF-L: 1,500 kg
MFU-40: Approx. 240 kg (with W8 feeders loaded)
BTU-AII: Approx. 120 kg, BTU-B: Approx. 15 kg, MTU-AII: Approx. 615 kg (with trays/feeders loaded)
