Wear Resistant SMT AOI Machine GKG G3 G5 PCB Test Equipment
Name: GKG AOI machine
Brand: GKG
Model: GKG G3 AOI machine
Specification: GKG G3 AOI machine
Condition: original/copy
Quality: top qualiy
Stock: large
Payment: L/C T/T D/P Western Union Paypal Money Gram And Others
Shipment: In three days
Warranty: 1 year
Delivery: fedex,ups,dhl,as required
Package: carton box with foam protect
G5 is high accuracy and high stability of the fully automatic
printing machine vision,GKG followed in SMT industry is the
development trend of production of a new generation of fully
automatic printing machine with the international leading
technology synchronous vision, visual processing of high
resolution, high precision of the transmission system,
suspension adaptive scraper.
Specification :
GKG Series High Precision Automatic Solder Paste Printer designed
for high precision
steel mesh printing or stencil printing in SMT industry.
Printing PCB size:50mm x 50mm ~400x340mm;
PCB thickness: 0.4mm ~ 6mm
FPC thickness: ≦0.6mm (Excluding jig)
1,All new 3rd generation stencil X beam structure, add solder paste
operators more convenient and accurate placement
steel net;New type torque X beam, solve the solder paste and dust
deposition, prolong the service life of the machine;
2,Scalable on pressure device, in view of easy deformation of the
PCB printing can make the tablet out, don't need
to use pressure for a little while can back again. According to the
product flexible use
3,The whole machine use imported self-lubricating guide rail, guide
rail need not add lubricant, within five years guide
free maintenance within five years.
4,X Y1 Y2 in U.S. HAYDON linear motor, the Japanese precision drive
screw, self-lubricating guide rail, to ensure accuracy
5,Net frame Y to automatically locate, can quickly realize
automatic stencil counterpoint;
6,Curved blade beam using high strength steel, in the printing
process to ensure the stability of the print head;
Floating type scraper system, the unique elastic stay device, can
very good protection in scraper drop process
stencil and scraper.
| Item | Parameter |
| Repeat Position Accuracy | ±0.01mm(Test data and method are available) |
| Printing Accuracy | ±0.025mm(Test data and method are available) |
| Printing Speed / Cycle Time | <8s (Exclude Printing & Cleaning) |
| Products Changeover | <5Min |
| Screen Stencil Size/Min-Max | 737mm X737mm |
| Screen Stencil Size/Thickness | 20mm ~ 40mm |
| PCB Size/Min-Max/Thickness | 50X50mm-400X370mm/0.4~6mm |
| PCB Warpage Ratio | ＜1%(Based on diagonal length) |
| Bottom of Board Size | 15mm(Standard configuration), 25mm |
| Edge of Board Size | 3mm |
| Conveyor Height | 900±40mm |
| Conveyor Direction | Left-Right; Right-Left; Left-Left; Right-Right |
| Conveyor Speed | 100-1500mm/sec Programmable control |
| Board Positioning | Support System | Magnetic pin/Side support block/Flexible automatic pin(optional) |
| Clamping System | Elastic side clamping/Vacuum nozzle/Extension-type Z-direction
table setting |
| Print head | Two indepandent Motorised printheads |
| Squeegee Speed | 6~300mm/sec |
| Squeegee Pressure | 0-10kg software control(closed-loop pressure feedback), pressure value visible |
| Squeegee Angle | 60°(Standard )/55°/45° |
| Squeegee Type | Steel squeegee (standard), rubber squeegee, and other types of
squeegee shall be customized. |
| Steel Mesh Separation Speed | 0.1~20mm/sec Programmable Control |
| Cleaning Method | Dry-type, wet-type, vacuum-type ( Programmable combination of
Cleaning methods) |
| Table Adjustment Range | X:±3mm; Y:±7mm θ:±2° |
| Type of Fiducial Point | Standard geometry shape of fiducial point, bonding pad / Stencil
hole |
| Camera System | Single digital camera for upward/downward vision system |
| Air Pressure | 4~6Kg/cm2 |
| Air Consumption | Approx 0.07m3 /min |
| Control Method | PC Control |
| Power Supply | AC:220±10%,50/60HZ 1Φ 1.5KW |
| Machine Dimensions/Weight | Depends on exactly model |
| Operation Temperature | -20°C ~ +45°C |
| Operation Humidity | 30%~60% |
